Excessive heat can gradually degrade rubber materials, leading to deteriorating performance and premature failure. As such, high-temperature applications require high-temperature-resistant rubber products that offer dependable performance no matter what. Natural rubber should not be used in applications with continuous temperature of above 85 °C. For some high-temperature applications, that simply isn’t high enough. However, certain synthetic grades of rubber have been chemically engineered to deliver superlative heat resistance in excess of 300 °C.
Here is our guide to four of the most impressive high-temperature-resistant rubber materials.
FKM (Viton®)
FKM is a family of fluoroelastomers commonly referred to by DuPont’s Viton® brand name. FKM is an excellent high-temperature-resistant rubber, which retains its good mechanical properties and chemical resistance (oils, fuels, lubricants and most mineral acids), even at extremely high temperatures.
Products moulded in FKM remain elastic when exposed to air oven ageing up to 205°C or intermittent exposures up to 316 °C. Commonly used in O-rings and other moulded or extruded products, this extreme temperature rubber also provides the best fluid resistance of any commercial rubber.
EPDM
Synthetic rubber, ethylene-propylene-diene monomer (EPDM), is a copolymer of ethylene, propylene and diene monomers. This synthetic high-temperature-resistant rubber offers excellent heat resistance, performing optimally up to +150°C. It also delivers excellent tear, abrasion, steam and compression set resistance.
While resistant to dilute acids, ketones and alkalis, EPDM rubber offers poor resistance to petroleum-based fuels, most oils and non-polar solvents. EPDM is often used as a lower-cost polymer thanks to its many favourable characteristics, especially its heat-resistant properties.
HNBR
Hydrogenated acrylonitrile-butadiene rubber (HNBR) is a unique elastomer that is derived from conventional nitrile rubber through the hydrogenation of unsaturated bonds in the butadiene. HNBR is an exceptionally high-temperature-resistant rubber that can withstand much higher temperatures than conventional nitrile up to +150 °C.
HNBR also offers excellent resistance to oils, fuels, many chemicals, steam and ozone, as well as exceptional tensile and tear strength. It also offers good abrasion resistance. However, this particular extreme temperature rubber is relatively expensive and incompatible with aromatic oils or polar organic solvents.
CSM (Hypalon)
CSM offers excellent resistance to dry heat up to +120 °C, provides excellent resistance to ozone, UV, weathering and corrosive chemicals when cured. CSM exhibits good electrical properties, low flammability and low gas permeability. However, this high-temperature-resistant rubber material offers relatively poor fuel resistance and low compression set.
Xiamen Fuste is a professional rubber parts manufacturer with more than 17 years.Our design team is available to consult on configurations and materials. Our aid with thoughtful design can also enhance end item appearance.We can quote for you according to drawing,samples or ideas.For more info ,please don't hesitate to contact me :sales1@fuste.com.cn.
